SLR 108 Aerial Ladder

The SLR 108 is Sutphen’s tandem axle rear mount aerial ladder, offering departments a powerful alternative to the traditional midmount design. Built on a tandem axle chassis with huck-bolted aerial construction and a 3:1 safety factor, the SLR 108 delivers strength and dependability for high-demand responses. Its 108-foot ladder operates without a torque tube and is stabilized by two sets of underslung jacks, while a narrow 16-foot jack spread provides a secure setup in tighter spaces.

With 115 feet of ground ladders and a full suite of heavy-duty features, the SLR 108 is designed for departments that need reach, reliability, and maximum equipment capacity. Whether for urban fire response or complex rescue scenarios, the SLR 108 stands ready.

Specs

Roof
Monarch 62” and 73” flat roof and raised roof options
Front Suspension
Front Axle and Suspension 23,000 lbs.
Rear Suspension
Rear Axle and Suspension 48,000 – 52,000 lbs.
Bumper
Standard 12” bumper with optional 6”, 18”, 24” or 30” extension options. Available in stainless steel, stainless steel channel and painted
Engine Options
Cummins L 9 400 HP or 450 HP Cummins X 12 425 HP, 450 HP, or 500 HP Cummins X 15 600 HP
Transmission Options
Allison Gen 5 EVS 3000 Allison Gen 5 EVS 4000
Wiring
Point-to-Point or Multiplex wiring systems
Type
Hale or Waterous, 1500 to 2000 GPM
Standard Pump Equipment
(2) 6” main suction, (2) 2.5” discharges left, (1) 2.5” discharge right, (1) 3″ discharge right, (2) 1.5” crosslay, (1) 3” tank to pump, and (1) 1.5” tank fill
Pump Panel
Black vinyl, brushed, or mirrored finish stainless pump panel
Water Tank
300-500 gallon water tank
Body
#304 Stainless Steel bolted body, Huck® bolt to the chassis frame
Space
Up to 240 cu. ft. of usable compartment spaceD
Doors
Roll up doors or hinged doors offered in painted or non-painted satin finish
Ladders
Alco-Lite or Duo-Safety ladders with a minimum of 115′ aerial compliment
Wheelbases
236″ with 62″ Cab 247″ with 73″ Cab
Sections
4-section ladder
Nozzle
1500 GPM monitor/nozzle
Waterway
Pinnable waterway at the 3rd or 4th section
Waterway Inlet
Pre-piped 4″ aerial waterway inlet. Standard pre-plumbed from pump, available with direct inlet at the rear of the vehicle
Cab Storage
EMS/storage cabinet in the cab
Bumper Storage
Hose storage, front suction, front discharge in the bumper
Inlet
Multiple pump inlet, discharge and crosslay options
System
Foam system
Power
Generator
Setup
Numerous electrical and scene lighting setups

Features

Feature IconStrongest Aerial Device in the Industry
Feature IconLower Aerial Maintenance
Feature IconHeavy Duty Body
Feature IconUnderslung Jacks
Feature IconGround Ladder Storage
Feature IconHeavy Duty Cab Interior
Feature IconMultiple Seating Configurations
Feature IconRear Mount Offering
