Industrial 95’ Aerial Platform Fire Truck

Industrial 95’ Aerial Platform

The Industrial 95-Foot Aerial is built for maximum flow and heavy-duty performance in high-demand environments. With the highest flow rating in the industry, it can deliver up to 4,000 gallons per minute from a pressurized source—even at full extension. Designed for both water flow and rescue operations, it’s a versatile solution for industrial and specialized fire response.

Built on a rugged stainless steel body and rated for wind speeds up to 50 mph, the Industrial 95 offers pump options tailored to meet complex industrial needs. From massive suppression to dependable reach, it’s engineered to perform when failure isn’t an option.

Specs

Chassis
Monarch 56”, 62”, cab options with flat or 10” and 15” half raised roof options
Front Axle
Front Axle and Suspension 24,000 lbs.
Rear Axle
Rear Axle and Suspension 58,000 lbs.
Bumper Options
12” bumper standard, optional 6”, 18”, or 24” extension options. Optional steel or steel channel, painted bumper
Engine
Cummins ISX 12 500 HP or ISX 15 600 HP
Transmission
Allison EVS 4000
Wheelbase
Standard 270” Wheelbase (with 56” cab)
Pump
Hale 8fg 3000 gpm
Foam System Options
Foam Pro Accumax or National Foam Servo Command, or Williams Hot Shot
Discharges
(3) 6” right, (1) 2.5” right, (1) 2.5” left, foam concentrate discharge 3” right or left, (2) 1.75” crosslay, 5” rear discharge
Monitors
(2) TFT Monsoon, Akron Masterstream, or Elkhart Scorpion, 2000 gpm each, remote operated
Water Tank
Tank capacity for up to 1000 gallons of foam and/or water
Body
#304 Stainless Steel bolted body, Huck bolted to the chassis frame
Hosebed Capacity
Hosebed Capacity for up to 700’ of 6” LDH
Air Bottle Storage
Capacity for up to 7 air bottles stored in the fender wells
Doors
ROM roll up doors in painted or brushed finish. Hinged doors optional
Ladders
Alco-Lite ladders, aerial compliment
Sections
5-section ladder
Nozzles
(2) 1000 GPM monitors/nozzles, one each side of the platform
Air
4500 psi breathing air to the platform
Power
120 volt outlet in the platform
Mid-Mount Design
Mid-mount design allows for a lower center of gravity, resulting in a more stable and better handling apparatus.
Stabilizer System
Patented “X” Jacks stabilizer system
Strength
Huck-bolted, 4-sided box design boom provides superior strength and rigidity, and results in a 3:1 safety factor.
Minimize damage
Aerial waterway and hydraulics are totally enclosed in the box boom reducing the risk of damage and costly repair expense.
Climate and Heat Protection
Aerial is constructed of #6061-T6 aluminum that will withstand extreme climate and intense heat situations. The aerial is left unpainted for ease of maintenance and lower repair cost.
Tip Load
The aerial device is rated with a 1000# tip load when dry, and 750# while flowing water.

Features

Feature IconThe Strongest Aerial Device in the Industry
Feature IconHighest Flow of Any Platform in the Industry
Feature IconLower Center of Gravity
Feature IconSutphen Signature Mid-Mount Design
Feature IconEase of Maintenance and Serviceability
Feature IconHeavy Duty, But Not Heavy
Feature IconNo Need for a Torque Box
Feature IconMultiple Seating Configurations
