Industrial 75′ Aerial Ladder Fire Truck

Industrial 75′ Aerial Ladder

The Industrial 75-Foot Ladder is a tandem axle, straight-stick aerial designed for high-capacity industrial firefighting without the added weight of a platform. Featuring a four-section box boom and a tighter wheelbase, it delivers exceptional maneuverability while maintaining the strength and stability required for demanding operations. It can be configured to carry foam and water or foam only, making it ideal for specialized industrial response.

With versatile pump options and heavy-duty monitors capable of flowing over 4,000 gallons per minute, the Industrial 75 is built for high-output suppression. This aerial delivers the reach, reliability, and power needed to protect critical infrastructure.

Specs

Chassis
Sutphen 62” with half 10” Raised Roof
Cab
Four-Door, Seven-Person Cab
Front Axle
Front Axle and Suspension 24,000 lbs.
Rear Axle
Rear Axle and Suspension 52,000 lbs.
Engine
Cummins ISX 11.9 , 500Hp
Alternator
Leece Neville 320 Amp
Transmission
Allison EVS 4000
Pump
Hale
8 FG – 3000GPM
Discharges
3” Right, (3) 6” Right, (2) 4” Deck Gun, 8” Aerial Waterway
Water Tank
500-Gallon Water Tank
Foam System
Accumax 300 Foam Pro
Foam Tank
1000-Gallon Foam Tank
Body
Sutphen
Finish
Stainless Steel
Space
140 cu. ft. Total Compartment Space
Signal
Federal Signal Q2B
Lights
Whelen LED Warning Lights
Power
Harrison Generator 10kw

Features

Feature IconThe Strongest Aerial Device in the Industry
Feature IconHighest Flow of Any Platform in the Industry
Feature IconLower Center of Gravity
Feature IconSutphen Signature Mid-Mount Design
Feature IconEase of Maintenance and Serviceability
Feature IconHeavy Duty, But Not Heavy
Feature IconNo Need for a Torque Box
Feature IconMultiple Seating Configurations
