SPH 100 – Western Reserve Joint Fire District, OH

Specs

Cab
Four-door, six-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
52,000 lbs
Engine
Cummins ISX 12, 500 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS4000
CSU-1500 GPM, Single
Stage
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
Crosslays
(1) 2 ½”, 2 ½” Swivel and (2) 2” Crosslays with 1 ½” Swivel
Water Tank
300-gallon
Construction
Huck bolted #304 stainless steel
Doors
Rom roll-up compartment
Total Compartment Space
Over 293 cu. ft. of compartment space
Ladder Compliment
Alco-lite ladders (115’, 14’, 16’, 16’, 24’ 2-section, 35’ 2-section and 10’ f)
Left 56” H/
Right 56” h
Bumper Extension
6”
FRC Seon, 360
Camera
Siren
Federal q2b
Power
10kw smart generator
Power
Hannay electric cord reel, 175’ (1)
Telescopic LED Scene
Light
Pike Pole Storage
Tube (6)
Intercom System, FRC
Act 2-station
Driver Side Monitor
Akron 3482 Stream Master2, Electric 1250 GPM
Officer Side Monitor
Akron 3483 Stream Master2, Manual 1250 GPM
Officer Side Nozzle
Akron 2499 & 3488 Pipe
