SPH 100 – Rocky Point Fire District, NY

Location:
Shoreham, NY
Department:
Rocky Point Fire District

Specs

Cab
Four-door, eight-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
52,000 lbs
Engine
Cummins X 12, 500 HP
Alternator
C.E. Niehoff, 360 AMP
Transmission
Allison 4500 Series
Water Pump
Qmax-1500 gpm, single stage pump
Discharges
(2) 2 ½” Left, (2) 2 ½” Right
Crosslay
(1) 2” w/ 1 ½” Swivel
Water Tank
450-gallon
Construction
Huckbolted #304 stainless steel
Doors
Hinged compartment
Total Compartment Space
Over 280 cu. ft.
Alco-Lite Ladder Package (149’
(2) 16’; 18’; (2) 24’ 2-Section; 35’ 2-section and 10’F)
Body
SPH-3, Left 56” H / Right 56” H
Bumper Extension
12” formed steel channel bumper
Siren
Federal q2b , grille mount
FRC, Inview 360
Camera system
Power
10kw smart generator
7 SCBA Cylinder
Compartments
17’ Little Giant
Included
Power
Hannay electric cord reel, 175’ (1)
FRC Spectra 12V
Brow light
Whelen LED Lightbar
Included
Whelen L31 LED
Beacons
FRC Spectra 240V
Led scene lights
FRC Spectra Surface
Mount 12v led scene lights
Boom Tracking Lights
Included
Driver Side Monitor
TFT monsoon, Manual 1250 GPM w/ Manual VUM
Officer Side Monitor
TFT Monsoon, Manual 1250 GPM w/ Manual VUM
Driver Side Nozzle
TFT MST-4NJ Stacked Tips w/ XF-SS10 Stream Straightener
Officer Side Nozzle
TFT MST-4NJ Stacked Tips w/ XF-SS10 Stream Straightener
