SPH 100 – Ravenswood Fire Department, WV

Location:
Ravenswood, WV
Department:
Ravenswood Fire Department

Specs

Cab
Four-door, four-person
10” Double Domex
Frame rails, tandem axle - aerial (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
52,000 lbs
Engine
Cummins X 12 500HP
Alternator
Leece Neville, 420 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Qmax-2000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right
Crosslay
(1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
Water Tank
300-gallon
Construction
Huckbolted #304 stainless steel
Doors
Sph mixed roll up and hinged compartment
Total Compartment Space
Over 280 cu ft.
Duo-Safety Ladder Package
115’
Body
SPH-3, LEFT 56" H / RIGHT 56" H
Bumper Extension
12” formed steel channel,
Siren
Federal q2b , grille mount
Camera System
Brigade, Backeye 360 Camera System
Intercom System
FRC ACT 2-Station
Power
Hannay electric cord reel, 150’ (1)
Generator
Smart Power, 10KW HYD
Whelen 72” Freedom
Iv led lightbar
FireTech, 72” 3-Piece
12v led brow
12V Spectra Scene
Light
FireTech 12V Scene
Light
FR Spectra 240V
Tele lights
Driver Side Monitor
Elkhart Cobra EXM 1250 GPM w/ Elkhart SM-1250E w/ 248A Stream Shaper
Officer Side Monitor
Akron 3483 Stream Master2, Manual 1250 GPM
Officer Side Nozzle
Akron 5160 Auto
