SPH 100 – Mankato Fire Department, MN

Location:
Mankato, MN
Department:
Mankato Fire Department

Specs

Cab
Four-door, five-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
52,000 lbs
Engine
Cummins X 12, 500HP
Alternator
Leece Neville, 420 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Csu-2000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
Crosslays
(1) 2 ½” Crosslays, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
Water Tank
400-gallon
Water Tank
20-gallon foam tank
Construction
Huckbolt #304 stainless steel
Doors
Hinged compartment
Total Compartment Space
Over 280 cu ft.
Duo-Safety Ladder Package
101’: 10’F; 14’; 18’; 24’ 2-Section; & 35’ 2-Section
Body
SPH-3, Left 56” H / Right 56” H
Bumper Extension
18” polished stainless steel,
Siren
Federal q2b , grille mount
Intercom System
Wireless Firecom 5100D, Single Radio
Power
Hannay electric cord reel, 150’ (1)
Inverter
2KW Aims Industrial
Camera System
FRC, Inview Trueview, Single Camera
FireTech 12V 3-Piece
Brow light
FireTech Aerial Spotlights
Included
FireTech 120V Guardian
Elite tele lights
Whelen Freedom IV
Wecanx 72” lightbar
Whelen M9 12V
Scene lights
Whelen L31 Warning
Beacon
Driver Side Monitor
Akron 3482 Stream Master2, Electric, 1250 GPM w/ Akron 5177 Electric Nozzle
Officer Side Monitor
Akron 3483 Stream Master2, Manual 1250 GPM
Officer Side Nozzle
Akron 2499 & 3488 Pipe
