SP 70 – Midland Fire and Rescue, NC

Truck Type:
SP 70 Aerial Platform
Dealer:
Sutphen
Location:
Midland, NC
Department:
Midland Fire and Rescue

Specs

Cab
Four-door, four-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
31,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-2,000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper
Crosslay
(2) 2” Valve-Piping w/ 1 ½” Swivel
Water Tank
500-gallon
Doors
Hinged compartment
Total Compartment Space
01 cu. ft. compartment space
Ladder Compliment
Duo-safety ladder package ((2) 30’ 3-section, ( 2) 16’ roof and (2) 10’ folding)
Body
SAA-1, Left High/Right Low
Bumper Extension
30” formed steel channel bumper
Siren
Federal q2b , grille mount
Camera System
FRC, Inview Trueview
Power
6kw onan generator
4 Bottle Compartments
Included
HiViz 3-piece 12v
Led brow light
Whelen Freedom 4
Lightbar
FRC Spectra 240v
20k surface mount telescopic lights
Firetech LED Rear
Work lights
Whelen L31 Beacons
Included
Whelen M6V2 Warning
Lights
