SL 75 – Swanton Fire Department, OH

Location:
Swanton, OH
Department:
Swanton Fire Department

Specs

Cab
Four-door, four-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
31,000 lbs
Engine
Cummins L9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1500 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper
Monitor
Akron 3480 Stream Master2 Elec RF w/ 5178 Nozzle
Crosslays
(2) 2” Valve-Piping 1 ½” Swivel
Water Tank
500-gallon
Water Tank
30-gallon foam tank
Foam System
Hale Smartfoam 2.1A
Construction
Huckbolt #304 stainless steel
Doors
Rom roll-up compartment
Total Compartment Space
Over 210 cu ft.
Alco-Lite Ladder Package
16’ R, 35’ 3-Section, 24 2-Section, (1) 10’ F
Body
SAA-4, Left High / Right Intermed / Trans
Bumper Extension
24” polished stainless steel,
Siren
Federal q2b , grille mount
Intercom System
FRC ACT 2-Station
Camera System
FRC, Inview Trueview, Single Camera
Wheel Chocks
Ziamatic electric ladder rack
Whelen PFH2 12V
Led brow light
Whelen Freedom 4
Lightbar
Whelen Mirco MPB
12v rear work lights
