SL 75 Aerial Ladder – Clay, NY

Specs

Cab
Four-door, six-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
31,000 lbs
Engine
Cummins L 9, 450HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1750 gpm 6” suction, single stage pump
Discharges
(1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper
Crosslays
(3) 2” Valve Piping w/ 1 ½” Swivel
Water Tank
500-gallon
Construction
Huckbolt #304 stainless steel
Doors
Hinged compartment , painted
Total Compartment Space
Over 192 cu ft.
Duo-Safety Ladder Package
(2) 16’ R, 24’ 2-Section, 35’ 3-Section, (2) 10’ Folding
Body
SAA-4, Left High / Right Intermed / Trans
Bumper Extension
24” formed steel steel,
Siren
Federal q2b , grille mount
Whelen Freedom IV
Lightbar
FRC Spectra LED
Brow light
FRC Spectra 20K
12v led scene light
Intercom System
FRC ACT 2-Station
