Demo 456, Custom Pumper
Truck Type:
Dealer:
Sutphen
Location:
Demo 456, Custom Pumper
Department:
Demo 456, Custom PumperSpecs
Cab
Four-door, six-person
10” Frame Rails
(50k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
24,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1500 gpm single stage
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Crosslays
(2) 2” with 1 ½” Swivel
Water Tank
30-gallon foam tank
Water Tank
750-gallon
Construction
3/16” extruded aluminum
Doors
Amdor roll-up
Total Compartment Space
246 cu. ft.
Alco-Lite PEL-24 (24’
2-section & prl-14 14’ roof & 10’ folding)
Brigade Backeye 360
Camera system
Siren
Federal q2b
Cab
Clean exterior compartment slide outs
Cab
Clean interior ceiling
FRC Spectra Brow
Light
Whelen Freedom LED
Lightbar
Bumper Extension
24”
Gallery
