Demo 451, SL 75 Aerial Ladder
Truck Type:
Dealer:
Sutphen
Location:
Demo 451, SL 75
Department:
Demo 451, SL 75Specs
Cab
Four-door, six-person
10” Frame Rails
(50k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
31,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1500 gpm single stage
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper
Crosslays
(2) 2” Valve-Piping with 1 ½” Swivel
Monitor
Elkhart 7250 Cobra EXM with SM1500E Nozzle
Water Tank
30-gallon foam tank
Water Tank
500-gallon
Construction
Huck bolted #304 stainless steel
Doors
Amdor roll-up
Total Compartment Space
Over 192 cu. ft.
Ladder Compliment
Alco-lite quint (85’, 16r’, 24’ 2-section, 35’ 3-section & 10’f)
FRC Inview Trueview
Single camera system
Siren
Federal q2b
Power
6kw smart generator
Power
Hannay electric cord reel, 150’ (1)
Bumper Extension
24”
Whelen Freedom 4
Lightbar
FRC Spectra 20K
12v led brow light
Gallery
