Custom Tanker – Union Township Fire Co., PA

Location:
Winfield, PA
Department:
Union Township Fire Co.

Specs

Cab
Four-door, six-person
10” Domex Double
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
48,000 lbs
Engine
Cummins X 12 500HP
Alternator
Leece Neville 320 AMP
Transmission
Allison Gen 5, EVS 4500
Water Pump
Qmax-1500 gpm single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (2) 2 ½” Left Rear, (1) 3” Deck Gun
Crosslays
(3) 2” w/ 1 ½” Swivel
Water Tank
2,500-gallon
Construction
3/16” extruded aluminum
Doors
Amdor roll up compartment
Total Compartment Space
Over 148 cu. ft.
Alco-Lite Ladder Compliment
28’ 2-section, 16’ Roof & 10’ Folding
Body
SWT-04A WetSide Tanker Tandem, Pump Module
Bumper Extension
12” polished stainless steel
Siren
Federal q2b , grille mount
Camera System
FRC, Inview TrueView, Single Camera
Wheel Chocks
Ziamatic quic-lift electric ladder rack
Water Tank
Portable tank, 2,500 gallon
Whelen 72” Freedom
Led lightbar
Whelen 36” Traffic
Advisor
FRC Spectra Brow
Light
FR Spectra Scene
Lights
Whelen L31 Beacons
Included
