Custom Tanker – Thompson Hose Company, PA

Location:
Thompson, PA
Department:
Thompson Hose Company

Specs

Cab
Four-door, eight-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
23,000 lbs.
Rear Axle and Suspension
48,000 lbs.
Engine
Cummins X 12, 500HP
Alternator
Leece Neville 320 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Qmax-2000 gpm, single stage pump
Discharge
(2) 2 ½” Left, (2) 3” Right, (1) 3” Pipe to Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Crosslays
(2) 2” w/ 1 ½” Swivel
Water Tank
1,800-gallon
Water Tank
20-gallon foam tank
Foam System
Akron 95 GPM 3096 By-Pass w/ Flush to (1) 1 ½” Discharge Line
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment
Alco-Lite Ladder Package
PEL-24, 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
Total Compartment Space
Over 530 cu. ft.
Body
TA-05 – Tanker 56/53 High/High Ladder Rack
Bumper Extension
18” polished stainless steel,
Siren
Federal q2b , grille mount
Camera System
FRC, Inview Trueview, Single Camera
Hannay Booster Reel
W/ 200’
72” Freedom Lightbar
Included
FireTech 3-Piece Brow
Light
FireTech Guardian Elite
Jr scene lights
