Custom Tanker – Northern Union Join Fire District, OH

Location:
Richwood, OH
Department:
Northern Union Join Fire District

Specs

Cab
Four-door, five-person
10” Single Rails
Domex, single axle (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
35,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS 3000
Water Pump
Qmax-xs 2000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Pipe to Right Rear, (1) 2 ½” Front Bumper Discharge
Crosslay
(1) 2 ½”
Speedlay
(2) 1 ½” w/ Lift-Out Trays
Crosslay
(1) 2 ½”
Water Tank
2,000-gallon
Water Tank
30-gallon foam tank
Foam System, Hale
Smartfoam 2.1a
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment
Total Compartment Space
Over 170 cu. ft.
Ladder Compliment
Alco-lite ladder package (pel-24 24’ 2-section & prl-14 14’ roof & 10’ folding)
Ladder Compliment
Ladder chute through tank
Body
TA-01 Tanker 56/53 High/Low Ladder Chute
Bumper Extension
24” polished stainless steel
Siren
Federal q2b , grille mount
Camera System
FRC, Inview Trueview, Single Camera
Power
Hannay electric cord reel, 200’ (1)
Generator
6KW Smart Power
Newton Swivel Dump
With electric dump
Whelen Freedom IV
72” lightbar
Whelen L31 Beacons
Included
FR Spectra Brow
Light
FR Spectra Scene
Lights (2)
