Custom Tanker – Community Fire Company, PA

Location:
Landingville, PA
Department:
Community Fire Company

Specs

Cab
Four-door, six-person
10” Double Frame
Rails (110k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
52,000 lbs
Engine
Cummins X 12, 600 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Qmax-1500 gpm single stage pump
Discharges
(2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Front/Right of Main Hosebed, (1) 3” Front Bumper, (1) 3” Deck Gun
Crosslays
(1) 2 ½”, 2 ½” Swivel
Speedlay
(2) 2” Crosslays w/ 1 ½”
Water Tank
3,000-gallon
Water Tank
30-gallon foam tank
Hale Smartfoam 2.1A
Included
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment
Total Compartment Space
Over 150” cu. ft.
Alco-Lite (PEL-24 24’’
2-section & prl-14 14’ roof & 10’ folding)
Body
TA-04 – Tanker 56/53 High/Low
Siren
Federal q2b , grille mounted
Bumper Extension
18” polished stainless steel
Power
Hannay electric cord reel, 150’ (1)
Generator
6KW Smart Power
Camera
FRC, Inview 360
Newton Dump Electric
Valve with swivel
Fire Tech Brow
Light with icc lights
Whelen Freedom 72”
Lightbar
Whelen LED, TAL85
47” traffic advisor
