Custom Rescue Pumper – Imperial Volunteer Fire Department, PA

Specs

Cab
Four-door, six-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
23,000 lbs
Rear Axle and Suspension
31,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 420 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Csu-2000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Speedlay
(2) 1 ½” w/ Liftout Tray and (1) 2 ½” Speedlay w/ Liftout Tray
Monitor
Elkhart 8393 Stingray Manual
Water Tank
1,000-gallon
Construction
3/16” extruded aluminum
Doors
Hinged compartment
Total Compartment Space
Over 640 cu. ft. compartment space
Ladder Compliment
Alco-lite ladder package (pel-24 24’ 2-section & prl-14 14’ roof & 10’ folding)
Body
PA-16 Res 56/53 Ladder Under Hosebed and Double Hatch
Bumper Extension
18” formed steel channel,
Siren
Federal q2b , grille mount
Power
Hannay electric cord reel, 200’ (1)
Camera System
FRC, Inview Trueview, Single Camera
Whelen Freedom 72”
Lightbar
Whelen 900 Warning
Lights
Whelen 36” Traffic
Advisor
HiViz Guardian Elite
Scene lights
HiViz 72” Brow
Light w/ marker lights
