Custom Pumper – Winston-Salem Fire Department, NC
Truck Type:
Dealer:
Location:
Winston-Salem, NC
Department:
Winston-Salem Fire DepartmentSpecs
Cab
Four-door, five-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
24,000 lbs
Engine
Cummins L 9, 450HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1500 gpm, single stage pump
Discharge
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2” Right/Front Hosebed, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Pipe to Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Crosslays
(1) 2 ½”, 2 ½” and (2) 2” Crosslays with 1 ½” Swivel
Water Tank
650-gallon
Construction
3/16” extruded aluminum
Total Compartment Space
234 cu. ft.
Doors
Hinged compartment
Ladder Compliment
Ladder chute
Alco-Lite PEL-24
Included
Bumper Extension
24”
Safety Vision Camera
System
Power
10kw smart generator
Pike Pole Chutes
(3)
Command Light Tower
Included
Power
Hannay electric cord reel, 175’ (1)
Whelen Freedom IV
Led light bar
