Custom Pumper – Turkey Creek Fire Territory, IN

Specs

Cab
Four-door, five-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
27,000 lbs
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1,500 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right Rear, (1) 2 ½” Left Rear, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Speedlay
(2) 2” w/ 1 ½” Swivel
Water Tank
1,000-gallon
Water Tank
25-gallon foam tank
Hale SmartFoam Foam
System
Doors
Rom roll-up compartment
Total Compartment Space
294 cu. ft. compartment space
Ladder Compliment
Alco-lite ladder package (24’ 2-section, 14’ roof and 10’ folding)
Body
G9-Alum 40/51
Bumper Extension
24” polished stainless-steel bumper
Siren
Federal q2b , grille mount
Camera System
FRC, Inview 360
Power
6kw smart generator
3 Bottle Compartments
Included
HiViz 72” Brow
Light
Whelen Freedom IV
Lightbar
Whelen M9 Scene
Light
Whelen M9 Warning
Lights
Whelen 600 LED
Red lights
FRC Spectra Telescopic
Lights
