Custom Pumper – Town of Clayton Fire District, NY

Specs

Cab
Four-door, six-person
10” Double Domex
Frame rails, single axle (110k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
24,000 lbs
Engine
Cummins L 9 450 HP
Alternator
Leece Neville, 420 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-1500 gpm single stage pump
Discharges
(1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Pipe Left Rear, (1) 3” Pipe Left Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper,
Crosslay
(2) 2” w/ 1 ½” Swivel
Water Tank
750-gallon
Water Tank
20-gallon foam tank
Foam System
Hale SmartFoam 2.1A
Construction
Huckbolted #304 stainless steel
Doors
Amdor roll up compartment
Total Compartment Space
Over 170 cu ft.
Duo-Safety Ladder Package
900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
Body
S1 – STS 30/50 L71H / R45H Ladder Bracket
Bumper Extension
24” polished stainless steel,
Siren
Federal q2b , grille mount
Camera System
Brigade, Single Camera
Whelen Freedom IV
72” led light bar
Whelen (2) PFH2
Led brow lights
Whelen PFH Tele
Lights
Whelen MCFLED LED
Beacons
