Custom Pumper – Rockledge, FL

Specs

Cab
Four-door, four-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
27,000 lbs
Engine
Cummins L 9, 450HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax – 1500 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper
Crosslays
(2) 2” Crosslays w/ 1 ½” Swivel
Water Tank
1000-gallon
Water Tank
20-gallon foam tank
Foam System
Foampro 2002, 5.0 GPM
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment , painted
Total Compartment Space
Over 246 cu ft.
Alco-Lite Pel-24 Ladders
(1) 24’ 2-section & (1) PRL-14 14’ Roof & (1) 10’ Folding
Body
G9 – Alum 40/51 Ladders Through Tank
Bumper Extension
24” formed steel channel,
Siren
Federal q2b , grille mount
Whelen Freedom LED
Lightbar
FRC Spectra Brow
Light
FRC Spectra Tele
Light
Whelen M9 Scene
Light
Camera System
Brigade 360
Whelen L31 Red
Led beacons
