Custom Pumper – North Fort Myers, FL

Specs

Cab
Four-door, six-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
27,000 lbs
Engine
Cummins L 9 450HP
Alternator
Leece Neville 320 AMP
Transmission
Allison Gen 5, EVS 3000
Water Pump
Xs qmax 1500 gpm single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Speedlays
(2) 2” w/ 1 ½” Swivels and Poly Lift-Out Trays
Crosslay
(1) 2 ½“
Water Tank
1,000 gallon
Water Tank
30 gallon foam tank
Discharges
Foam system, akron 125 gpm 3126 by-pass w/ flush to discharge line
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment , satin finish
Total Compartment Space
222 cu. ft.
Alco-Lite ladder package
PEL-24 24’ 2-sec & PRL-14 14’ Roof & 10’ Folding
Body
G9 – Aluminum 40/51 Ladder Chute
Bumper Extension
24” formed steel steel bumper
Siren
Federal q2b , grille mount
Intercom System
David Clark 5-Position
Camera System
Brigade 360 Camera
FRC Spectra LED
Scene
Whelen Freedom 72”
Led lightbar
Whelen M9 Red
Leds
