Custom Pumper – Laurence Harbor Fire Company, NJ

Specs

Cab
Four-door, six-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
19,000 lbs.
Rear Axle and Suspension
24,000 lbs.
Engine
Cummins L 9, 450HP
Alternator
Leece Neville 420 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Qmax-2000 gpm, single stage pump
Discharge
(2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 4” Deck Gun
Crosslays
(2) 1 ½” & (1) 2 ½” w/ Swivels
Water Tank
750-gallon
Water Tank
40-gallon foam tank
Foam System
Akron 95 GPM 3096 Internal Eductor
Construction
3/16” extruded aluminum
Doors
Amdor roll-up compartment
Total Compartment Space
Over 275 cu. ft.
Alco-Lite Ladder Package
PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
Body
S9 – Alum 43/53 Ladder through the Tank
Bumper Extension
18” formed steel channel,
Siren
Federal q2b , grille mount
Generator
Smart Power 10KW
Power
Hannay electric cord reel, 150’ (1)
Discharges
Tft monsoon electric deck gun
Camera System
Brigade, Backeye 360
Whelen Freedom IV
72” led light bar
FireTech 3-Piece 72”
Led brow light
FireTech Guardian Scene
Lights (8)
