Custom Pumper – Ellington Fire Department, CT

Truck Type:
Sutphen Heavy-Duty Custom Pumper
Dealer:
Sutphen
Location:
Ellington, CT
Department:
Ellington Fire Department

Specs

Cab
Four-door, six-person
10” Double Rails
Single axle (50k psi)
Front Suspension 20,000
Lbs.
Rear suspension 27,000lbs
.
Engine
Cummins L 9, 450 HP
Alternator
Leece Neville 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Xs qmax-1500 single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Speedlay
(2) 2” w/ Swivel and Poly Lift-Out Trays
Crosslay
(1) 2 ½”
Water Tank
1000-gallon
Water Tank
30 gallon foam tank
Foam System
Akron 125 GPM 3126 By-Pass w/ Flush
Construction
3/16 extruded aluminum
Doors
Rom roll-up compartment painted
Total Compartment Space
Over 220 cu. ft.
Body
G2 – Aluminum 40/51 Ladder Chute
Bumper Extension
24” polished stainless-steel bumper
Siren
Federal q2b , grille mount
Power
Hannay electric cord reel, 150’ (1)
Generator
Smart Power, 6KW
Firetech 3-Piece 72”
Led brow light
Whelen Freedom LED
Lightbar w/ (2) 21” mini freedom
Remote Control Go-Light
Included
Hi-Viz Minis 31”
Scene
FireTech 12V LED
Scene light
