Custom Pumper – Des Moines Fire Department, IA
Truck Type:
Location:
Des Moines, IA
Department:
Des Moines Fire DepartmentSpecs
Cab
Four-door, five-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
20,000 lbs w/ (4) 56” leafs
Rear Axle and Suspension
27,000 lbs
Engine
Cummins X 12, 525 HP
Alternator
Leece Neville 420 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Qmax-2000 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Valve 2 ½” Pipe to Left Rear, (1) 1 ½” Front Bumper, 2” Plumbing, (1) 3” Deck Gun
Crosslays
(2) 2” Valve-Piping 1 ½” Swivel
Water Tank
500-gallon
Construction
3/16” extruded aluminum
Doors
Mixed amdor roll-up and hinged compartment
Total Compartment Space
Over 320 cu ft.
Duo-Safety Ladder Package
900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
Body
PS-Custom with Lad Chute
Bumper Extension
18” polished stainless steel bumper
Intercom System
FireCom 5100D, Single Radio, 4 Position
Siren
Federal q2b, grille mount
Whelen PFH2 12V
Brow
Whelen PFH2 12V
Scene light
Whelen Freedom IV
Lightbar 72”
Whelen L31 LED
Beacons
Elkhart 8297 “Stinger”
W/ 8298 mount w/ quad stacked tips & stream shaper
Gallery
