Custom Pumper – Dalton Fire Department, GA

Specs

Cab
Four-door, five-person
10” Double Frame
Rails (50k psi)
Front Axle and Suspension
19,000 lbs
Rear Axle and Suspension
24,000 lbs
Engine
Cummins X 12, 500HP
Alternator
Leece Neville 320 AMP
Transmission
Allison Gen 5, EVS4000
Water Pump
Qmax-2000 gpm 6” suction single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Crosslays
(2) 2” Valve-Piping & (1) 1 ½” Swivel
Water Tank
750-gallon
Water Tank
30-gallon foam tank
Foam System
Elkhart W/ Flush
Construction
3/16” extruded aluminum
Doors
Hinged compartment roll-up compartment , satin finish
Total Compartment Space
Over 230 cu. ft.
Duo-Safety Ladder Package
900A 24’ 2-Section & 775DR 14’ Roof & 10’ Folding
Body
PA-12 Res 43/53 Ladder Chute
Bumper Extension
18” polished stainless steel bumper
Siren
Federal q2b , grille mount
Camera System
Inview Trueview, Two Cameras
Intercom System
Wired, Setcom, 6 Position
Whelen Freedom IV
(16) 72” led lightbar
Whelen TAL65 Traffic
Advisor
Whelen PFH2 12V
Led brow
Whelen M9 12V
Led scene
