Custom Pumper – Belmont Fire Department, SC

Specs

Cab
Four-door, five-person
10” Double Domex
Frame rails (110k psi)
Front Axle and Suspension
20,000 lbs
Rear Axle and Suspension
24,000 lbs
Engine
Cummins L 9, 380 HP
Alternator
Leece Neville, 320 AMP
Transmission
Allison Gen 5, EVS3000
Water Pump
Xs-qmax-1,500 gpm, single stage pump
Discharges
(2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
Crosslay
(1) 2 ½” Valve Pumping
Speedlay
(2) 2” w/ Swivels and Poly Lift-Out Trays
Water Tank
750-gallon
Water Tank
30-gallon foam tank
Elkhart Foam System
Included
Doors
Amdor roll-up compartment
Total Compartment Space
294 cu. ft. compartment space
Ladder Compliment
Ladder package (24’ 2-section, 14’ roof and 10’ folding)
Ladder Compliment
Enclosed ladder chute
Body
G9-Alum 40/51
Bumper Extension
18” formed steel channel bumper
Siren
Federal q2b , grille mount
Camera System
FRC, Inview Trueview
Power
6kw smart generator
3 Bottle Compartments
Included
FRC Spectra LED
Brow light
Siren
Federal navigator 73” lightbar
Siren
Federal fr9 led scene lights
Siren
Federal fr 9 warning lights
Siren
Federal ql64 led red lights
