Delivery Date:
05/01/2018
Department Name:
Wolfhurst Volunteer Fire Department
Department City / State:
Bridgeport, OH
Truck Type:
WHEEL BASE: 215”
TRAVEL HEIGHT: 9’ 10”
TRAVEL LENGTH: 33′ 10”
CHASSIS: Sutphen 62” Cab with 10” half raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 18,000 Lbs.
- Rear Axle and Suspension: 24,000 Lbs.
- Engine: Cummins L 9 450HP
- Alternator: Niehoff 360 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- QMAX-2000 GPM Single Stage
- Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing
- 750 Gallon Water Tank
BODY: Sutphen
- 222 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Hosebed Supports
- Park Brake Release
- Mirror Velvac, West Coast Style Stainless Steel, Heated & Remote
- Auxiliary Cab Steps, Alum Set of 4
- Intake Pressure Control Akron Style 53
- 5” Crosslay in Dunnage
- Crosslay Cover Hinged Treadplate with Vinyl Sides
