Delivery Date:
12/02/2024
Department Name:
Crystal Lake Fire Department
Department City / State:
Ellington, CT
Truck Type:
Dealer: MES-Shipman’s Fire
WHEELBASE: 199”
TRAVEL HEIGHT: 10’ – 7”
TRAVEL LENGTH: 32’ – 8 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab with a 10” Raised Roof
- Four-Door, Six- Person Cab
- Front Axle and Suspension 23,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 48,000 lbs
- Engine: Cummins X 12, 500HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4500
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper w/ 2 ½” Plumbing, (1) 3” Deck Gun
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 2500-Gallon Water Tank
BODY: Sutphen
- Stainless Steel Body
- Mixed Hinged and Amdor Roll Up Compartment Doors
- Nearly 140 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 35’ 3-Section, 16’ Roof & 10’ Attic
- Body: SWT-04A STS Wet Side Tanker Tandem, Pump Module
ADDITIONAL EQUIPMENT:
- 12” Formed Steel Bumper
- Federal Q2B Siren, Grille Mount
- Zico Extend Down Ladder Rack
- Camera System: FRC, Inview Trueview, Two Cameras (Wired)
- Whelen Freedom IV 72” LED Light Bar
- FireTech 3-Piece 72” LED Brow Light
- FireTech Guardian Scene Light
- Whelen L31 Beacons
- Whelen M2 Warning Light
MONITOR:
- TFT XFC-42 Crossfire w/ Safety Flow w/ Quad Stack Tips & Stream Shaper
