Delivery Date:
08/12/2018
Department Name:
Washington Township Fire Department
Department City / State:
Mansfield, OH

WHEEL BASE: 215”

TRAVEL HEIGHT: 9’-8”

TRAVEL LENGTH: 34’-7”

CHASSIS:             Sutphen 62” extended cab with half 10” raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front Left of Main Hosebed, (1) 2 ½” Left Rear, 1 ½” Front Bumper, (1) 3” Deck Gun
  • 40-Gallon Foam Tank
  • Waterous Advantus 6 and Tankvision Foam Gauge
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • Stainless Steel
  • ROM Roll-Up Doors
  • 234 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • 10KW Smart Power Generator
  • Duo-Safety Ladders
  • Hannay Electric Cord Reel, 200’
  • Command Light KL408-W1
  • Federal Q2B
  • 24” Bumper
  • Ladder Chute
