Delivery Date:
08/30/2024
Department Name:
Ingomar Volunteer Fire Company
Department City / State:
Pittsburgh, PA
Truck Type:

Dealer: FAST of the Allegheny Mountains

WHEELBASE: 233”

TRAVEL HEIGHT: 10’ – 7 ½”

TRAVEL LENGTH: 34’ – 2 ¼”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 20” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 No Pump, No Tank

BODY:                 Sutphen

  • 3/16” Extruded Aluminum
  • Mixed Roll-Up and Hinged Compartment Doors
  • Over 560 cu ft. Total Compartment Space
  • Body: RA-20 20’ Alum, Walk Around/Walk In, Single Axle

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FireCom 5100D Wireless Two-Position Intercom System
  • Hannay Electric Cord Reel, 150’ (2)
  • Generator: Onan, 25KW Direct Drive PTO
  • 12K Winch
  • Camera System: FRC, Inview Trueview, Single Camera
  • Bauer Air Compressor
  • Cylinder ASME Cascade System (4)
  • SCBA Bottle Storage (12)
  • Wilburt Light Tower w/ (4) Spectra Light Heads
  • Whelen Freedom IV 72” Lightbar
  • FR Spectra Brow Light
  • FireTech Guardian Elite Scene Lights
  • Whelen 900 Warning Lights
  • Whelen 47” Traffic Advisor
  • Whelen 21” Freedom Lightbars
