Delivery Date:
03/25/2020
Department Name:
Palm Beach County Fire & Rescue
Department City / State:
West Palm Beach, FL
Truck Type:
WHEELBASE: 245”
TRAVEL HEIGHT: 10’ – 3 ¼”
TRAVEL LENGTH: 35’
CHASSIS: Int’l HV613 – 2DR
- Two-Door, Two-Person Cab
- Front Axle and Suspension 18,000 lbs
- Rear Axle and Suspension 46,000 lbs
- Engine: A26 475 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- DSD – 1250 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 3000-Gallon Water Tank
BODY: Sutphen
- Hinged Compartment Doors
- 3 cu. ft. Total Compartment Space
- Fully Enclosed Ladder Chutes
- Body: SWT – 04B
ADDITIONAL EQUIPMENT:
- 20” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Air Bottle Compartments (4)
- Whelen PFP2 Brow Light
- FRC Spectra Scene Lights
- Whelen M9V2 Warning/Scene Lights
