WHEEL BASE: 185”
TRAVEL HEIGHT: 9’-10”
TRAVEL LENGTH: 31’-4”
CHASSIS: Suthpen 62” extended cab with half 10” raised roof
- Four-door, Five-person cab
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins ISL 9, 380 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 20-Gallon Foam Tank
- FoamPro 1600 System
- 1000-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Rom Roll-Up Compartment Doors
- Ladder Chute
- 222 cu. ft. total compartment space
- Alco-Lite PEL-24
OPTIONAL EQUIPMENT:
- David Clark Intercom System 6 Position
- Ziamatic SAC-44 Folding Wheel Chocks
- 18” Bumper
- Federal Q2B
