Sutphen Corporation – HS #6254-55
Dealer – Williams Fire Equipment
WHEEL BASE: 247”
TRAVEL HEIGHT: 11’-6”
TRAVEL LENGTH: 47’-10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000 with retarder
PUMP: Hale
- QMAX-2000 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right
- Crosslays: (2) 2” Valve-Piping, 1 ½” Swivel
- 300-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Amdor Roll-Up and Hinged Painted Compartment Doors
- Left High/Right High
- 293 cu. ft. Total Compartment Space
- Alco-Lite Ladder SPH (115’: 14’, 16’, 16’, 24’ 2-Section, 35’ 2-Section and 10’ F)
OPTIONAL EQUIPMENT:
- 12” Bumper Extension
- Camera System, Voyager, Split Screen, Wired (2)
- Hannay Electric Cord Reel, 200’ (1)
- Pike Pole Storage Tube (3)
- Whelen Freedom IV 72” LED Light Bar
- Intercom System, FR ACT 2-Station
MONITOR:
- Monitor: Driver Side, Akron 3473, Gemini Manual 1000 GPM
- Nozzle: Driver Side Akron 5460 Auto
- Monitor: Officer Side, Akron 3473, Gemini Manual 1000 GPM
