Sutphen Corporation – HS #6373
Dealer – Herb Fire Equipment
WHEEL BASE: 236”
TRAVEL HEIGHT: 11’ – 6”
TRAVEL LENGTH: 47’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS 4000
PUMP: Hale
- QMAX-2000 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left; (1) 4” Right; (1) 2 ½” Right, (1) 1 ½” Front Bumper
- Crosslays: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslay with 1 ½” Swivel
- 300-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- ROM Roll-Up Compartment Door
- Over 287 cu. ft. of Total Compartment Space
- Alco-Lite Ladder Compliment (121’: 14’, 16’, 18’, 28’ 2-Section, 35’ 2-Section & 10’ F)
- SPH-3: Left 56” High/ Right 56” High
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel Bumper Extension
- Federal Q2B Siren, Grille Mount
- Hannay Electric Cord Reel, 150’ (2)
- 10KW Smart Power Generator
- FRC Inview 360 Camera System
- FRC Spectra LED Tele Lights
- Whelen PFH2 LED Brow Light
- Whelen Traffic Advisor, TAL85 22” (2)
- Rigid Outrigger Spot Lights
- Rigid LED Boom Tracking Lights
- Roto-Ray Warning Light
MONITOR:
- Drive Side Monitor: Akron 3482 Stream Master2, Electric, 1250 GPM w/ Akron 5177 Electric Nozzle
- Officer Side Monitor: Akron 3473 Gemini Manual 1000 GPM
