Delivery Date:
10/17/2017
Department Name:
Norwich Township Fire Department
Department City / State:
Hilliard, Ohio

WHEEL BASE: 247”

TRAVEL HEIGHT: 11’- 6”

TRAVEL LENGTH: 48’

CHASSIS:              Sutphen 73” extended cab with half 10” raised roof

  • Four-door, Five-person cab
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins ISX 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX-1500
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
  • 300-Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • Hinged Compt. Doors
  • Alco-Lite SPH
  • 293 cu. ft. total compartment space
  • SPH-3, Left 56” High, Right 56” High

OPTIONAL EQUIPMENT:

  • 10KW Harrison Generator
  • Electronic Siren, Whelen
  • Warning Lights, Whelen
  • Pike Pole Storage Tubes
  • Stokes Arms
  • Parapet Ladder
  • Voyager 3 Camera System
  • Intercom System, FRC ACT 2-Station
  • Federal Q2B
  • Hannay Electric Cord Reel
  • 18” Bumper
  • M6 Scene Corner Lights

MONITORS:

  • Driver Side Monitor: Akron Stream Master2, Manual 1250 GPM
  • Driver Side Nozzle: Akron 1755 Turbomaster
  • Officer Side Nozzle: Akron 1755 Turbomaster
