WHEELBASE: 236”
TRAVEL HEIGHT: 11’ – 6”
TRAVEL LENGTH: 47’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a 10” Raise Roof
- Four-Door, Four-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 24,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins X 15, 600HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front Bumper
- Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
- 300-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Mixed Roll Up and Hinged Compartment Doors
- Nearly 300 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 14’, 16’, 16’, 24’ 2-Section, 35’ 2-Section & 10’ F
- Body: SPH-3, Left 56” H / Right 56” H
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Intercom System: LiberatorMax, Single Radio, 4 Position
- Generator: Smart Power, 6KW
- Camera System: Brigade, Backeye 360 Camera System
MONITOR:
- Driver Side Monitor: Akron 3482 Stream Master2, Electric, 1250 GPM w/ Akron 5177 Electric Nozzle
- Officer Side Monitor: Akron 3483 Stream Master2, Manual 1250 GPM
- Officer Side Nozzle: Akron 2499 & 3488 Pipe
