Delivery Date:
01/10/2019
Department Name:
Franklin Fire Department
Department City / State:
Franklin, TN
Truck Type:
Sutphen Corporation – HS #6322
Dealer – Southeast Fire
WHEEL BASE: 236”
TRAVEL HEIGHT: 11’ – 6”
TRAVEL LENGTH: 46’ – 1”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Idle Pro, 420 AMP
- Transmission: Allison Gen 5, EVS 4000
PUMP: Hale
- QMAX-2000 GPM Single Stage
- Discharges: (2) 2 ½” Left; (1) 4” Right; (1) 2 ½” Right
- Crosslays: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslay with 1 ½” Swivel
- 300-Gallon Water Tank
- 30-Gallon Foam Tank
- Akron Foam Supply System
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Amdor Roll-Up Compartment Door
- 293 cu. ft. of Total Compartment Space
- Alco-Lite 115’ (14’, 16’, 16’, 24’ 2-Section, 35’ 2-Section & 10’ Folding)
- Left 56” High/ Right 56” High
OPTIONAL EQUIPMENT:
- 6” Bumper Extension
- Federal Q2B Siren
- Pike Pole Storage Tubes (6)
- Safety Vision SVR-4100 DVR Camera System
- 8KW Smart Power Generator
- Power Arc Lightbar
- FRC Spectra Tele Lights
- Traffic Advisor Power Arc
- FRC ACT 2-Station Intercom System
- Hannay Electric Cord Reel, 150’ (1)
MONITOR
- Drive Side Monitor: Elkhart Cobra EXM 1250 GPM w/ Elkhart SM-1250 E w/ 248A Stream Shaper
- Officer Side Monitor: Akron 3483 Stream Master2, Manual 1250 GPM
- Officer Side Nozzle: Akron 2499 & 3488
