Delivery Date:
01/31/2024
Department Name:
Defiance Fire and Rescue
Department City / State:
Defiance, OH

Dealer –  Herb Fire

WHEELBASE: 236”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 47’ – 0”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ a 10” Raise Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, 6” Suction Single Stage Pump
  • Discharges: (2) 2.5” Left, (1) 3” Right, (1) 2 ½” Right
  • Crosslays: (1) 2.5”, 2.5” Swivel & (2) 2” w/ 1 ½” Swivel
  • 400-Gallon Water Tank

BODY:                  Sutphen

  • Huckbolt #304 Stainless Steel
  • Mixed AMDOR Roll-Up and Hinged Compartment Doors
  • Over 280 cu ft. Total Compartment Space
  • Alco-Lite Ladder Package (115’): 14’, 16’, 16’, 24’-2Sec, 35’-2Sec & 10’ F
  • Body: SPH-3, Left 56”H / Right 56”H

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC Act 2-Station
  • Camera System: FRC Inview Trueview, Two Cameras
  • Generator: Smart Power, 10KW
  • Hannay Electric Cord Reel, 150’ (1)
  • Whelen Freedom IV 72” Light Bar
  • 12V FR Spectra Brow Light
  • 12V FireTech Aerial Spotlights
  • 240V FR Spectra Tele Lights

MONITOR:

  • Driver Side Monitor: Akron 3482 Stream Master2, Electric, 1250 GPM w/ Akron 5177 Electric Nozzle
  • Officer Side Monitor: Akron 3483 Stream Master2, Manual 1250 GPM
  • Officer Side Nozzle: Akron 2499 & 3488 Pipe
