Sutphen Corporation – HS #6377-78
Dealer – Williams Fire Apparatus
WHEEL BASE: 221”
TRAVEL HEIGHT: 10′ – 9 ¼”
TRAVEL LENGTH: 42’ – 9 ¾”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
- Monitor: (2) Elkhart #293-6A W/CSW Nozzle
- Crosslays: (2) 2” Crosslays, 2” Valve-Piping 1 ½” Swivel
- 500-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Amdor Roll-Up Compartment Doors
- Over 192 cu. ft. Total Compartment Space
- Duo-Safety Quint Ladder Compliment (85’: 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding)
- SAA-4: Left High / Right Intermed / Transverse
ADDITIONAL EQUIPMENT:
- 12” Polished Stainless Steel Bumper Extension
- Voyager 2, Camera System
- 3200W Energizer Inverter Generator
- Pike Pole Storage Tubes (6)
- Federal Q2B Siren, Front Bumper Mount
- Whelen Freedom IV LED Light Bar
- LED Marker Lights
- FRC Spectra 12V LED Brow Light
- FRC Spectra 120V LED Tele-Light
