Delivery Date:
06/15/2021
Department Name:
Eden Fire Department
Department City / State:
Eden, NC
Truck Type:

Sutphen Corporation – HS #6812

Dealer – Stevens Fire Equipment

WHEELBASE: 221”

TRAVEL HEIGHT: 10’ – 9 ¼”

TRAVEL LENGTH: 43′ – 5 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 23,000 lbs.
  • Rear Axle and Suspension: 31,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, 6” Suction Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 1 ½” Front Bumper
  • Monitor: (2) Elkhart #293-6A w/ CSW Nozzle
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 190 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (85’: 16’ Roof; 24’ 2-Section; 35’ 3-Section; and 10’ Folding
  • Body: SAA-4 Left High / Right Intermed / Transverse

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview 360 HD
  • Generator: Harrison, Stinger 3.6KW
  • Hannay Electric Cord Reel, 150’ (1)
  • Whelen Freedom 4 Lightbar
  • FRC Vantagepoint LED Spotting Light
  • FRC Spectra LED Brow Light
  • FRC Spectra 120V LED Scene Light
  • FRC Spectra 900 Scene Light
