Delivery Date:
10/12/2018
Department Name:
Macon-Bibb County Fire Department
Department City / State:
Macon-Bibb, GA
Truck Type:
Sutphen Corporation – HS #6270
Dealer – Williams Fire Apparatus
WHEEL BASE: 258”
TRAVEL HEIGHT: 11’ – 4”
TRAVEL LENGTH: 50’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 44,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Waterous
- CSU-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
- Crosslays: (2) 2” Valve-Piping, 1 ½” Swivel
- 30-Gallon Foam Tank
- Elkhart Foam Supply System
- 500-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- ROM Roll-Up Compartment Doors
- Duo-Safety Ladders Aerials 117’ (14’, 16’, 18’, 24’ 2-Section, 35’ 3-Section and 10’ Folding)
- Body SP3 – Left High/Right Low
OPTIONAL EQUIPMENT:
- 18” Bumper Extension, 2” Raised Lid, and Full-Width, Deep-Center Trough
- Harrison 10KW Generator
- Hannay Electric Cord Reel, 150’ (1)
- Pike Pole Storage Tubes (6)
- Whelen Traffic Advisor
- Whelen Freedom IV LED Lightbar, 72”
- Whelen Mini Freedom IV LED Lightbar, 21”
Monitors:
- Monitor: Driver Side, Akron 3473, Gemini Manual 1000 GPM
- Nozzle: Driver Side, Akron 5160 Auto
- Monitor: Officer Side, Akron 3473, Gemini Manual 1000 GPM
- Nozzle: Officer Side Akron 5160 Auto
