WHEEL BASE: 220″
TRAVLE HEIGHT: 10′ 3/8″
TRAVEL LENGTH: 34′-2 1/4″”
CHASSIS: Sutphen 73” Cab with 10” half raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension: 23,000 Lbs.
- Rear Axle and Suspension: 31,000 Lbs.
- Engine: Cummins ISX 12 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Waterous
- CSU-1500 GPM Single Stage
- Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Valve & 2.5” Pipe to Left Rear, 2.5” Valve & 2.5” Pipe Right Rear, 2.5” Front/Left of Main Hosebed, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun, *Foam is plumbed to every discharge
- 1000 Gallon Water Tank
BODY: Sutphen
- Stainless Steel
- 253.3 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Hose Troughs
- Suction Hose Mounted Above Driver Side Compartments
- F4X4RR Whelen Freedom 44” LED
- Light Tower Command
- Gold Leaf Between the Paint Break Line on the Cab
- 4 Pike Pole Tubes
- Front Bumper Drop Down Door
- Front Suction Hose & Strainer
- Front Suction Valve Pre-Connect Valve
- 72” Suction Hose 6” Typically has to be Cut Down to Fit
