Delivery Date:
12/13/2024
Department Name:
Loveland Symmes Fire Department
Department City / State:
Loveland, OH
Truck Type:

Dealer – Heritage Fire Equipment

WHEELBASE: 206”

TRAVEL HEIGHT: 11’ – 9 ½”

TRAVEL LENGTH: 37’ – 11 ¼”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 35,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 6, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Valve 2 ½” Pipe Right Rear, (1) 1 ½” Front Bumper, 2” Plumbing, (1) 2 ½” Auxiliary Waterway
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel, One Deadlay
  • 480-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foam System: Hale SmartFoam 2.1A

BODY:                 Sutphen

  • Huckbolt #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Nearly 180 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: Quint 85’ 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding
  • Body: SAA-RM1, Left High / Right High

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC ACT 2-Station
  • Camera System: FRC, Inview Trueview, Single Camera (Wired)
  • Generator: Smart Power, 6KW Hyd
  • FireTech 3-Piece 12V LED Brow Light
  • Whelen Freedom IV 23” Rotabeam Lightbar
  • FireTech 12V LED Work Lights
  • Whelen McFled Rear Beacon

MONITOR:

  • Elkhart 7200X2 Cobra EXM2 w/ SM1500E Nozzle
