Delivery Date:
05/07/2024
Department Name:
Watertown Fire Department
Department City / State:
Watertown, MN
Truck Type:

Dealer – Custom Fire

WHEELBASE: 236”

TRAVEL HEIGHT: 12’ – 3”

TRAVEL LENGTH: 42’ – 2”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 24,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12 500 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 2 ½” Auxillary Waterway
  • Crosslay: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • 500-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foam System: FoamPro 2001, 2.6 GPM

BODY:                  Sutphen

  • Huckbolted #304 Stainless Steel
  • Hinged Compartment Doors
  • 220 cu. ft. Total Compartment Space
  • Ladder Package Duo-Safety: 12’ F, 14’, 14’, 16’, 24’ 2-Section, 35’ 2-Section
  • Body: SLR108-4 Left High / Right High, Full Hosebed Right
  • Monitor: Elkhart 7250 Cobra EXM w/ SM1500E Nozzle

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper
  • Federal Q2B Siren, Pedestal Mount
  • Camera System: Brigade, Two Camera
  • Inverter: Kussmaul 3000 Watt
  • Intercom System: FRC ACT 2-Station
  • Roto-Ray LED Warning Light
  • FireTech 3-Piece LED Brow Light
  • Whelen Freedom IV 21” Lightbar
  • FireTech Guardian 12V LED Scene Light
  • FireTech 12V Boom Spotlights
  • FireTech FT-MB-2.18 12V LED Scene Light
  • FireTech 12V LED Rear Work Lights
