Delivery Date:
08/23/2023
Department Name:
Murrells Inlet - Garden City Fire District
Department City / State:
Murrells Inlet - Garden City, SC
Truck Type:

Dealer – Williams Fire Apparatus

WHEELBASE: 247”

TRAVEL HEIGHT: 12’ – 3”

TRAVEL LENGTH: 42’ – 2”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a Flat Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12 500 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4500

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
  • Crosslay: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • 500-Gallon Water Tank
  • 20-Gallon Foam Tank

BODY:                  Sutphen

  • Huckbolted #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 230 cu. ft. Total Compartment Space
  • Ladder Package Duo-Safety: 14’ Combo; 14’ R; 16’ R; 16’ R; 28’ 2-Section; 24’ 2-Section; 35’ 2-Section & 10’ F
  • Body: SLR108-1, Left High/Right High, Shallow Hosebed Left
  • Monitor: TFT Y5-E11A-L Typhoon Electric w/ M-ERP-1500 Nozzle

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel, Bumper
  • Federal Q2B Siren, Grille Mount
  • Hannay Electric Cord Reel, 200’ (1)
  • Camera System: FRC, Inview 360HD w/ Built-In DVR
  • FireTech 12V LED Boom Spotlights
  • FireTech 3-Piece 72” LED Brow Light
  • FRC Spectra 15K 12V LED Scene Light
  • Whelen Freedom IV RotaBeam (2) 21” LED Light Bars
  • Whelen Summit 44” 12V LED Scene Light
  • Whelen TAL65 Traffic Advisor
