Delivery Date:
06/15/2022
Department Name:
Wausau Fire Department
Department City / State:
Wausau, WI
Truck Type:

Sutphen Corporation – HS #7120

Dealer – Custom Fire Apparatus

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 0 ½”

TRAVEL LENGTH: 42’ – 1 ¼”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (1) 2 ½” Left, (1) 2 ½” Right, (1) 4” Right, (1) 2 ½” Pipe to Left Rear, (2) 2 ½” Front/Right of Main Hosebed
  • Crosslay: (2) 2” Valve-Piping, 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • Hinged Compartment Doors
  • Over 193 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Compliment: (14’ R, 16’ R, 24’ 2-Section, 35’ 3-Section & 10’ F)
  • Body: SAA-3, Left High / Right Intermed
  • Monitor: Akron 3480 Stream Master2 Electric RF w/ 5178 Nozzle

ADDITIONAL EQUIPMENT:

  • 12” Formed Steel Channel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Two Cameras
  • Intercom System: Firecom 5100D, 4 Positions
  • Generator: 3.6KW Harrison Stinger
  • Hannay Electric Cord Reel, 150’ (1)
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Whelen PFH2 12V LED Brow Light
  • Whelen Freedom 4 Lightbar
  • Whelen PCPSM2 12V LED Scene Light
  • Whelen TANF65 Traffic Advisor
  • FireTech 12V LED Boom Spotlights
