Delivery Date:
08/14/2024
Department Name:
Swanton Fire Department
Department City / State:
Swanton, OH
Truck Type:
Dealer – Herb Fire
WHEELBASE: 221”
TRAVEL HEIGHT: 10’ – 0 ½”
TRAVEL LENGTH: 41’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a 10-Inch Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper
- Monitor: Akron 3480 Stream Master2 Elec RF w/ 5178 Nozzle
- Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
- 500-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Hale Smartfoam 2.1A
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- ROM Roll-Up Compartment Doors
- Over 210 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: 16’ R, 35’ 3-Section, 24 2-Section, (1) 10’ F
- Body: SAA-4, Left High / Right Intermed / Trans
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Intercom System: FRC ACT 2-Station
- Camera System: FRC, Inview Trueview, Single Camera
- Ziamatic Electric Ladder Rack
- Whelen PFH2 12V LED Brow Light
- Whelen Freedom 4 Lightbar
- Whelen Mirco MPB 12V Rear Work Lights
