Delivery Date:
11/04/2024
Department Name:
Nichols Hills Fire Department
Department City / State:
Nichols Hills, OK
Truck Type:

Dealer –  Heartland Fire Trucks

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 1”

TRAVEL LENGTH: 42’ – 9”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10-Inch Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 24,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 35,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Valve 2 ½” Pipe Right Rear, (1) 2 ½” Upper Left Side Body, (1) 2 ½” to Front Bumper
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                 Sutphen

  • Huckbolt #304 Stainless Steel
  • Mixed Amdor Roll-Up and Hinged Compartment Doors
  • Over 230 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: Quint 85’ 16’ R, 24’ 2-Section, 35’ 3-Section & 10’ Folding
  • Body: SAA-4, Left High / Right Intermed / Trans

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC ACT 2-Station
  • Camera System: Brigade, Two Camera (Wired)
  • Roto Ray LED
  • Whelen Freedom IV 72” Lightbar
  • FireTech 3-Piece 12V LED Brow Light
  • FireTech 12V LED Boom Spotlights

MONITOR:

  • Elkhart 7205 Cobra EXM w/ SM1500E Nozzle
