Delivery Date:
10/11/2023
Department Name:
Hoover Fire Department
Department City / State:
Hoover, AL
Truck Type:

Dealer – Williams Fire Apparatus

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 1”

TRAVEL LENGTH: 41’ – 5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 35,000 lbs
  • Engine: Cummins X 12 500HP
  • Alternator: Delco Remy, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front Bumper
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • Huckbolted #304 Stainless Steel
  • Amdor Roll-UpCompartment Doors
  • 227 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 14’ R, 16’ R, 28’ 2-Section, 35’ 3-Section & 10’ Folding
  • Body: Left High / Right High Split / Extended Length / Transverse

ADDITIONAL EQUIPMENT:

  • 20” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: Pro-Vision 900 DVR System
  • Intercom System: FRC ACT 2-Station
  • Hannay Electric Cord Reel, 150’ (1)
  • FRC Spectra 12V LED Brow Light
  • Opticom
  • Whelen Freedom 4 81” Lightbar
  • Whelen Mini Freedom 23” Lightbars
  • FireTech FT-MB-2.24-FT 12V LED Scene Light
  • FRC Spectra 28K 120V LED Scene Light

MONITOR:

  • Monitor: TFT Y5-E11A-L Typhoon Electric w/ M-ERP-1500 Nozzle
